Kev piav qhia

ADW210

Acrel ADW2XX series rail-type multi-loop fais fab ntsuas ntsuas yog siv los ntsuas tag nrho cov hluav taws xob tsis zoo ntawm ntau lub voj voog peb-theem, Txog li plaub-theem peb-theem voj tam sim no tuaj yeem txuas nrog ib txhij. Nws tuaj yeem ntsuas qhov voltage thiab tam sim no, lub zog, lub zog muaj zog, lub kaum sab xis, tsis sib npaug, sib haum xeeb thiab lwm yam tsis muaj.

Qhov tseeb

Lub zog muaj zog: chav kawm 1
Reactive zog: chav kawm 2

Ntau zaus

Ntau yam: 50 - 60Hz

Pulse tso zis

Active pulse output thiab reactive pulse output

Kev noj haus

<0.5VA(Single phase)

Qhov Loj (L * W * H)

Vaj huam sib luag loj (L × W): 72 * 97.7 * 36 mm

Wireless

Kev sib kis ntawm 470MHz thiab qhov siab tshaj plaws nyob rau hauv qhov chaw qhib yog 1km; 2 G; NB

Pib tam sim no

4 Ib lb

xxxx

Specification		3 theem 3 xov hlau, 3 theem 4 xov hlau
Qhov hluav taws xob	Rated Voltage	3*220/380V
	Kev noj haus	<0.5VA
Tam sim no	Input Tam sim no	5A,100A
	Kev noj haus	<0.5VA
Qhov tseeb	Tam sim no	Chav kawm 0.5
	Lub zog muaj zog	Chav Kawm 1
	Reactive zog	Chav kawm 2
Kev sib txuas lus		RS485 (Modbus-RTU)
txheeb ze humidity		Tsawg dua lossis sib npaug li 95% (Tsis muaj condensation)
Cov ntsiab lus	L * W * H (mm)	7297.936
Kub	Kev khiav haujlwm	-25 ~ 55 degree
Kub	Kev khaws cia	-40 ~ 80 degree
Cov av noo		Tsawg dua lossis sib npaug li 95% (Tsis muaj condensation)
Qhov siab		<2000m

Muaj nuj nqi

ADW210 Series rail-type multi-loop AC Peb Theem Zog Saib Xyuas Lub Zog Hluav Taws Xob yog tsuas yog siv rau tag nrho cov hluav taws xob ntsuas ntsuas ntawm ntau lub voj voog peb-theem. Lawv muaj peev xwm ib txhij txuas mus rau cov tswv yim tam sim no txog li plaub-theem peb-theem loops.

ADW210

●N (1, 2, 3, 4) peb-theem Circuit Court puv hluav taws xob ntsuas ntsuas, sab nraud tam sim no transformer;

● Saib xyuas peb-theem voltage / tam sim no, xoom ntu ntu tam sim no, thiab zaus;

● Saib xyuas peb-theem fais fab, tag nrho lub zog (active, reactive, thiab pom tseeb);

● Saib xyuas peb-theem fais fab tuag thiab tag nrho cov fais fab tuag;

● Saib xyuas voltage / tam sim no lub kaum sab xis, voltage / tam sim no tsis sib npaug degree;

● Saib xyuas qhov voltage thiab tam sim no tag nrho cov harmonics thiab 2-31 sub-harmonics;

● Cov ntaub ntawv siab heev ntawm qhov hluav taws xob, tam sim no, thiab lub zog ntawm lub hli tam sim no thiab lub hli dhau los;

●Qhov siab tshaj plaws tam sim no, qhov xav tau lub zog siab tshaj plaws, thiab lub sijhawm tam sim no, lub sijhawm xav tau lub zog tiag tiag;

●200 cov ntaub ntawv xwm txheej, kaw DIDO ua;

● Txhawb nqa dhau-voltage, dhau-tam sim no, theem tsis ua haujlwm, DI txuas, thiab lwm yam tso tawm tswb;

●4- lub sij hawm zone 14- lub sij hawm tus nqi teev;

● Plaub-quadrant hluav taws xob, 12-hli ntau tus nqi hluav taws xob hluav taws xob txheeb cais;

●31 hnub ntawm plaub-quadrant thiab ntau tus nqi hluav taws xob lub zog khov, rau pem hauv ntej thiab rov qab hluav taws xob ntsuas hluav taws xob;

●Ob txoj kev hloov cov tswv yim, ob txoj kev hloov cov zis, RS485 kev sib txuas lus, cov khoom siv mem tes tawm (lub voj sib txuas tuaj yeem hloov tau).

Expanded Communication Module --- AWT100:

● AWT100

● 4G (Global general module)

● WiFi

● LoRaWAN

● LoRa

● NB-IoT

Expanded Module	Kev piav qhia
AWT100 Communication Module	4G (Global General Module)
	4G (South American module)
	LoRaWAN ({0}} MHz, 923MHz)
	LoRa (460 ~ 510 MHz)
	NB-IoT

nthuav davCable Temperature & Residual Current Measurement Module --- MTL

●MTL

● Kev ntsuas kub: -20 degree ~+100 degree

● Kev ntsuas tam sim no: 10 ~ 3000 mA

● Qhov tseeb: Kub: ± 2 degree; Residual tam sim no: 1% (Class 1)

product-482-408

Expanded Module	Kev piav qhia
-MTC Kub & Residual Tam sim no Ntsuas Module	Kev ntsuas kub	-20 degree ~ +100 degree
	Kev ntsuas qhov seem tam sim no	10 ~ 3000mA
	Qhov tseeb	Kub: ± 2 degree; Residual tam sim no: 1% (Class 1)
	Fais fab mov	DC 12V; Kev siv: Tsawg dua lossis sib npaug rau 1W; RJ45 interface
	Kev sib txuas lus	RJ45 interface; MODBUS-RTU (kev sib txuas lus nrog lub ntsiab lub cev)

nthuav davDO/DI Hloov Ntxiv Kev Ua Haujlwm Module --- MK

● MK

● 12 channel DI (Digital Input)

● 4 channel DO (Digital Output)

product-482-408

Expanded Module	Kev piav qhia
- MK Hloov Module	12 × DI (cov tswv yim)	Qhuav contact input nrog built-in fais fab mov
	4 × DO (tso zis)	Relay nquag qhib kev sib cuag tawm; Kev ntsuas hluav taws xob AC 250V / 3A, DC 30V / 3A
	Fais fab mov	DC 12V; Kev siv: Tsawg dua lossis sib npaug rau 1W; RJ45 interface
	Kev sib txuas lus	RJ45 interface; MODBUS-RTU (kev sib txuas lus nrog lub ntsiab lub cev)
